This is for a pair of used Server Technology CWG-24VYL415C9 CXG Switched POPS PDUs 208V 3-Phase C13 C19 L21-30P. Each PDU has 25 outlets (total of 50 outlets). These are full-featured Server Tech PDUs with individual outlet power metering, monitoring and switching capabilities. This includes power metering of each individual outlet.
- Includes one master Server Technology CWG-24VYL415C9 and one link CWG-24VYL415C9 Switched POPS PDUs 208V 3-Phase C13 C19 L21-30P as pictured above. Also includes button mounting hardware and a link cable. No other parts or accessories are included.
- These PDUs are in good working and in good cosmetic condition. Cosmetic defects include light scratches, scuff marks, and velcro tape. Please see photos as these are the actual units that you will receive.
Technical Specifications
Input
- Input Voltage (V): 208 3-Phase
- Frequency: 50/60 Hz
- Input Plug: NEMA L21-30P
- Input Current (A): 20
- Input Current Rated (A): 16
Output
- Output Connectors: (18) x IEC 60320/C13, (6) x IEC 60320/C19, (1) NEMA 5-20R (per PDU)
Key Features
- Network Monitoring: Gain access to valuable data through connections including HTTP(S), SSH, Telnet, SNMP, (S)FTP, SMTP, Syslog, LDAP(S), RS-232 serial, and more.
- Outlet Control: Individual outlet remote on/off switching. Cycle power to individual outlets or groups of outlets to reboot servers. Or, power off unused receptacles.
- POPS (Per Outlet Power Sensing): Monitor Current Load (A), Voltage (V), Power (W), Apparent Power (VA), Crest Factor and Power Factor per outlet at an accuracy of ±2%.
- PIPS (Per Input Power Sensing): Accurately measures Active Power, Apparent Power, Energy k-Wh, Power Capacity, and Power Capacity Used using the network interface. See the aggregate current draw, in Amps, locally using the onboard LED.
- Branch Circuit Protection: This PDU meets the UL and IEC 60950-1 requirement for branch circuit protection through use of UL248 fuses.
Product Information
Manufacturer: Server Technology
MPN: CWG-24VYL415C9, CXG-24VYL415C9
Shipping Weight: 42 lbs.
Shipping Dimensions: 74 x 6 x 6 Inches
